John Deere 1E 23 Sub-Compact Tractor
| Make | John Deere |
| Model | 1E 23 |
| Type | 1-Family Compact Tractors |
Your Preferred Location
Description
- One-Piece Hood Design for Easier Maintenance
- Hydro Transmission With Twin Touch™ Pedals for Ease of Use
- AutoConnect™ Mid-Mower Deck can be Installed or Removed Quickly Without Leaving the Seat
- High‑Back Suspension Seat With Marine‑Grade Vinyl and Armrests for Lasting Comfort
Models
Convenient Twin Touch™ Foot Controls
Twin Touch™ foot controls let operators change speed and direction with a touch of the toe, making loader and mower work faster and easier. Benefits include infinite ground speeds, no clutching for quick reversals, strong startup torque, and reduced drivetrain shock.
Equipment Mobile and Smart Connector
Equipment Mobile helps you set up, operate, and maintain your tractors from one app. With a John Deere Smart Connector, you can see live tractor data, get DTC alerts, track maintenance, scan the PIN for manuals and parts, and manage your fleet more efficiently in one place.
More Time Working, Less Time Switching Implements
John Deere Compact Tractors are built for fast, tool-free implement changes, enabling users to switch tasks efficiently. With Quick Connect Solutions like the AutoConnect™ Deck System, Quik-Park™ Loader, iMatch™ Quick Hitch, and Quik-Knect™ PTO connector, operators can attach or detach implements in under a minute—often without leaving the seat.
Specifications
- Capacities - Fuel Tank Capacity: 5.6 gal.
- Capacities - Fuel Tank Capacity: 21.2 L
- Electrical System - Alternator Capacity: 40 amp
- Engine - Air Cleaner Type: Dual element with mechanical restriction indicator
- Engine - Aspiration: Natural
- Engine - Cooling System Type: Water pump
- Engine - Displacement: 61 cu in.
- Engine - Emissions Certifications: Final Tier 4
- Engine - Engine Model: 3TNM74F-NCJT
- Engine - Fuel Type: Diesel
- Engine - Number of Cylinders: 3
- Engine - Rated Engine Power: 22 PS
- Engine - Rated Engine Power: 16 kW
- Engine - Rated Engine Power: 22 hp
- Engine - Rated Engine Speed: 3200 rpm
- Front PTO - PTO Speed: 3200
- Hydraulics - Hydraulic System Type: Open center
- Machine Configuration - Wheel or Track Configuration: Wheel
- Rear Hitch - Draft Control Sensing: Select control
- Rear Hitch - Maximum Lift Capacity at 610-mm Behind Hitch Point: 758
- Rear Power Take-Off (PTO) - Brake (For Mid and Rear PTO): Wet disk
- Rear Power Take-Off (PTO) - Engagement Method: Independent
- Tires - Front Tires Size: R3 Turf: 18x8.50-10; R4: 18x8.5-10
- Transmission - Clutch: Wet disc
- Transmission - Cruise Control: No
Features
- Engine - Displacement: 61 cu in.
- Engine - Rated Engine Power: 22 hp
- Engine - Engine Model: 3TNM74F-NCJT
- Engine - Rated Engine Power: 22 PS
- Engine - Rated Engine Power: 16 kW
